This 3-bedroom house plan features a master bedroom with an ensuite bathroom and a walk-in closet, two additional bedrooms sharing a common toilet and bath, a lounge and dining area. The front porch provides direct entry into the lounge, while the kitchen is complemented by a back porch for added functionality and convenience.
This 3-bedroom house plan is designed to deliver comfortable, functional, and well-organized family living. The layout balances private bedroom spaces with spacious shared areas, making it suitable for modern residential development.
Floor Layout Arrangement
The floor layout includes the following spaces:
Master bedroom with ensuite bathroom and walk-in closet
Bedroom 1
Bedroom 2
Common toilet and bath
Lounge
Dining area
Kitchen
Front porch
Back porch
The arrangement allows smooth movement between rooms while maintaining privacy and practicality.
Elevations
The drawing set includes North, South, East, and West elevations, clearly illustrating the external appearance of the house. These elevations highlight the roof form, wall finishes, window and door placements, and overall architectural proportions.
Building Section
A detailed building section (cross-section) is provided to show vertical construction details, including floor levels, wall heights, ceiling lines, and the roof structure. This section assists builders in understanding the relationship between structural elements.
Door and Window Schedules
The plan includes door and window schedules specifying sizes and number of doors and windows needed.
Roof Design
The plan features a simple hidden roof.
Sewer connection
The sewer connection is made up of the inspection chambers and the septic tank. The connection ensures proper disposal of waste water.
General Construction Details
General construction details are provided to guide key building elements such as foundations, wall construction, and standard structural details, supporting smooth and accurate execution on site. The clients details such as the names and proposed location for development can be filled in the clients details section on the plan.
