This simple 2-bedroom house plan is designed for modern, practical living. It features an entry porch, a comfortable lounge, a functional kitchen, two bedrooms, a common toilet and bath, and a dedicated laundry area. The hidden roof design gives the house a clean, modern exterior appearance while remaining a cost-friendly roofing option, making this plan ideal for homeowners seeking a stylish yet affordable home.
This simple 2-bedroom house plan is designed for modern, functional, and cost-effective living. The compact layout and hidden roof design give the house a clean contemporary appearance while keeping construction practical and affordable.
Floor Layout Arrangement
The floor layout includes the following spaces:
Entry porch
Lounge
Kitchen
Bedroom 1
Bedroom 2
Common toilet and bath
Laundry area
Elevations
The drawing includes North, South, East, and West elevations, clearly illustrating the external appearance of the house. The elevations highlight the clean lines and modern look created by the hidden roof design, while showing wall finishes, openings, and overall building proportions.
Building Section
A building section is provided to give vertical detail about the house. It reveals the internal organization, construction details (like walls, roofs, foundations) and spatial heights.
Door and Window Details
The plan includes door and window schedules showing the total number of doors and windows needed for the house and their dimensions.
Roof Design (Hidden Roof)
The house features a hidden roof design, where the roof structure is concealed behind parapet walls. This creates a modern, flat-roof appearance while using conventional roofing materials underneath. The design is cost-friendly, reduces visual clutter, and offers a contemporary aesthetic without the high cost of complex roof systems.
Drainage Connection
The drainage system is made up of inspection chambers (manholes), septic tanks and soak pits. They are responsible for handling drainage and waste water management.
General Construction Details and clients details
General construction details are the general instructions to help guide in construction. the client details section allows the clients to fill in their personal details on the plan such as their names, plot number and proposed location for development. This details show ownership.
