This 3-bedroom house plan offers a practical layout suited for everyday family living. It includes a master bedroom, two additional bedrooms sharing a common bathroom and toilet, a comfortable lounge and a functional kitchen. A welcoming entry porch provides direct access into the lounge. This plan is ideal for people who need a simple economical design.
The architectural drawing includes North, South, East, and West elevations, showing the external appearance of the house from all sides. These elevations illustrate wall finishes, window and door placement, roof profile, and overall building proportions.
Building Section
A detailed building section (cross-section) is provided to show vertical construction details, including floor levels, wall heights, ceiling lines, and roof structure. This section helps builders clearly understand the design during construction.
Door and Window Details
The plan includes door and window details specifying sizes and number of doors and windows needed for the house.
Roof Design
The roof design is a gable roof design.
Sewer connection
The sewer connection is made up of the inspection chambers and the septic tank. The connection ensures proper disposal of waste water.
General Construction Details and client details
General construction details are included to guide key building elements such as foundations, wall construction, and standard structural details, ensuring smooth execution during construction. The clients details such as the names and proposed location for development can be filled in the clients details section on the plan.
