This 3-bedroom house plan features a gable roof design and a functional family-oriented layout. It includes a master bedroom with an ensuite bathroom, two additional bedrooms sharing a common toilet and bathroom and comfortable living spaces comprising a lounge and dining area. The kitchen is complemented by a store, while the entry porch provides direct access into the lounge, making this plan suitable for practical residential living.
The arrangement promotes smooth circulation between rooms while maintaining privacy and efficient use of space.
Elevations
The architectural drawing set includes North, South, East, and West elevations, showing the external appearance of the house from all sides. These elevations illustrate the building’s form, wall finishes, door and window placement, and roof profile, helping visualize the final completed home.
Building Section
A building section (cross-section) is provided to show vertical details about the house, revealing interior details like floor heights, ceiling structures, roof structure, wall thickness and relationships between floors that aren’t visible in plans or elevations.
Door and Window Details
The plan includes door and window schedules detailing sizes of the doors, windows and the quantity or number needed. These schedules support accurate material estimation and budgeting.
Roof Design
The roof design is a gable roof which is an economical and beautiful option to go with.
Sewer Connection
The drawing includes a sewer connection layout showing the location of inspection chambers (manholes). These chambers guide wastewater flow from the house to the septic tank, allowing for easy inspection, maintenance, and efficient waste management.
General Construction Details and client details
General construction details just give general information about the development. The client details section allows the clients to fill in their personal details on the plan such as their names, plot number and proposed location for development. This details show ownership.
